Brand new in box
Manufacturer direct shipping
2 year limited manufacturer's warranty
Authorized Aims Power dealer
Free shipping

Features:

  • ETL Listed to UL 458 Standards and CSA 22.2 No 107.1
  • 2000 watt low-frequency inverter
  • 6000-watt surge for 20 seconds -3x surge capability
  • Battery Priority Selector
  • Terminal Block
  • GFCI - 20 amps
  • Marine Coated and Protected
  • Multi-Stage Smart charger 70 Amp
  • remote panel available
  • auto gen start
  • auto frequency
  • 10msec typical transfer time
  • 7 battery type settings for the charger
  • selectable 25W power save mode (hibernation)

    Specifications:

    Inverter Output Specifications:

    • Listed to UL 458 Standards
    • Continuous Output Power: 2000 Watts
    • Surge Rating: 6000 Watts (20 Seconds)
    • Output Waveform: Pure Sine/Same as input (Bypass Mode)
    • Output Voltage: 100-110-120Vac
    • Nominal Efficiency: >92% (Peak)
    • Line Mode Efficiency: >95%
    • Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
    • Typical Transfer Time: 10ms (Max)
    • Bypass terminal breaker - 30 amps
    • THD: < 10% DC
    • Ambient operating temperature: 14°F to 122°F (-10°C to 50°C)

    Input Specifications:

    • Nominal Input Voltage: 12.0Vdc
    • Minimum Start Voltage: 10.0Vdc
    • Low Battery Alarm: 10.5Vdc-11.0Vdc
    • Low battery Trip: 10.0Vdc-10.5Vdc
    • High Voltage Alarm: 16.0Vdc
    • Low battery Voltage Restart: 13.0Vdc
    • Idle Consumption: 28 watts
    • Charger breaker - 20 amps
    • Power Saver Mode Idle Consumption: <12.7 watts

    Charger Specifications:

    • Output voltage: Depends on battery Type
    • Charger Rate: 70A

    Dimensions:

    • Unit Weight: 47.4 lbs.
    • Unit Size L x W x H: 15.35 x 11 x 7 inches
    • Shipping Weight: 55 lbs.
    • Shipping L x W x H: 20.5 X 13.8 X 12.2 inches

              As an Aims Power authorized dealer, we offer a 2 year limited factory warranty on this item.

              Aims Power inverters have a one to two year warranty. If it is a ETL listed inverter it has a two year, all other models have a one year.
