Aims Power PICOGLF6024120UL 6000 Watt Pure Sine Inverter Charger ETL Listed to UL 458 New
Manufacturer: Aims Power
SKU: PICOGLF6024120UL
QTY
(888) 999-1522
$ 2,260.00
This item ships for free. Freight shipments include liftgate at no additional charge.
Select Bread as your payment at checkout
In Stock
ON SALE!
Special! Use the following coupon code at checkout for 2% off: AIMS25 COPY
Ships in (est) 1-2 business days
Extended Warranty
Factory Warranty
- 2 Year Manufacturer Warranty
Extended Warranties
-
Extends factory warranty to 2, 3, or 5 total years
-
Covers functionality issues for 2, 3, or 5 years
-
Local repair options always available
-
Free replacement if repair is not possible
-
No deductibles or hidden fees
-
Full parts and labor coverage
$0
(Included)
- 2 Year Manufacturer Warranty
(Details)
-
Extends factory warranty to 2 total years
-
Covers functionality issues for 2 years
-
Local repair options always available
-
Free replacement if repair is not possible
-
No deductibles or hidden fees
-
Full parts and labor warranty
(Details)
-
Extends factory warranty to 3 total years
-
Covers functionality issues for 3 years
-
Local repair options always available
-
Free replacement if repair is not possible
-
No deductibles or hidden fees
-
Full parts and labor warranty
(Details)
-
Extends factory warranty to 5 total years
-
Covers functionality issues for 5 years
-
Local repair options always available
-
Free replacement if repair is not possible
-
No deductibles or hidden fees
-
Full parts and labor warranty
Exceptional Customer Service
Authorized Dealer
Similar Products
Customers Also Purchased
Aims Power PICOGLF6024120UL 6000 Watt Pure Sine Inverter Charger ETL Listed to UL 458 New
Product Overview
Brand new in box
Manufacturer direct shipping
Factory Warranty Included
Authorized Aims Dealer
Features
- 6000 Watt Low Frequency Inverter
- 18000 Watt Surge For 20 Seconds 300% Surge Capability
- 24 Volt DC
- Single Phase 120Vac Output
- Listed to UL 458, 1741, 1012 and CSA 22.2 NO. 107.1 & 107.2
- Battery Priority Selector
- Terminal Block
- Marine Coated and Protected
- Multi Stage Smart Charger 60 Amp Charges GEL, Lead, AGM, Lithium
- Remote Panel Available LED or LCD
- Auto Frequency
- 10msec Typical Transfer Time
- Selectable 25W Power Save Mode (hibernation)
- 7 Battery Type Settings For Charger
- Allows Start Up and Through Power With Depleted Batteries
Specifications
| Continuous output power | 6000 Watts |
| Surge rating | 18000 Watts (20 Seconds) |
| Output waveform | Pure Sine/Same as input (Bypass Mode) |
| Output voltage | 100-110-120Vac |
| Output breaker | 80 Amps |
| Nominal efficiency | >88% (Peak) |
| Line mode efficiency | >95% |
| Output frequency | 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz |
| Typical transfer time | 10ms (Max) |
| THD | < 10% DC |
| Ambient operating temperature | 14°F to 122°F (-10°C to 50°C) |
| Nominal input voltage | 24.0Vdc |
| Minimum start voltage | 20.0Vdc |
| Low battery alarm | 21.0Vdc-22.0Vdc |
| Low battery trip | 20.0Vdc-21.0Vdc |
| High voltage alarm | 32.0Vdc |
| Low battery voltage restart | 26.6Vdc |
| Idle consumption | 52.5 watts |
| Idle consumption with power saver mode ON | <25 watts |
| Output voltage | Depends on battery Type |
| Charger rate | 60A |
| Over charge protection shutdown | 31.4V |
| Unit Weight | 108 lb. |
| Unit Size L x W x H | 19 x 16.5 x 8 inches |
| Transfer Switch | 80a |
Package Contents
Aims Inverter
Owner's manual
Warranty
2 Year Manufacturer Warranty
