Aims Power PICOGLF60W48V240VS 6000 Watt Pure Sine Inverter Charger New
The AIMS Power low frequency 6000 Watt 48-volt, split phase 120/240 Vac power inverter charger is not your average every-day power inverter. This is a  top-of-the-line power inverter, built for the purpose of running a small house, business office or large RV. This inverter charger is perfect for your off grid system or for use as an emergency backup supply. Built with a 48 volt DC input, this inverter performs with very little power loss. Users receive a notable increase in efficiency in large systems when compared to using inverters that accept 12 or 24 volts. This can be an attractive feature for sustainability lovers looking to live as efficiently as possible.
Overview (Right Column)

Brand new in box

Manufacturer direct shipping

Factory Warranty Included

Authorized Aims Dealer


Features (Left Column)
  • 6000 Watt Low Frequency Inverter 110-120 Volt
  • 18000 Watt Surge for 20 Seconds -3x Surge Capability
  • Split Phase 110/120/220/230/240 Vac
  • Battery Priority Selector
  • AC Direct Connect Terminal Block
  • Marine Coated and Protected
  • Multi Stage Smart Charger 60 Amp Charges GEL, Lead, AGM, Lithium
Features (Right Column)
  • Remote Panel Available
  • Auto Gen Start
  • Battery Temp Sensor Available
  • Resettable Circuit Breakers
  • 10msec Typical Transfer Time
  • Optional 25W Power Save Mode
  • 7 Battery Type Settings for Charger
Product Specifications (Left Column)
  • Continuous Output Power: 6000 Watt
  • Surge rating: 18,000 Watt (20 seconds)
  • Output waveform: Pure Sine/Same as Input (bypass mode)
  • Output voltage: 100-110-120/220/230/240 VAC – split phase 120 & 240Vac
  • Nominal efficiency: >88% (peak)
  • Line mode efficiency: >95%
  • Output frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
  • Typical transfer time: 10ms (Max)
  • THD: < 10% DC
  • Ambient operating temperature: 14°F to 122°F (-10°C to 50°C)
  • Nominal input voltage: 48 VDC
  • Minimum start voltage: 44 VDC
  • Low battery alarm: 42 Vdc-44  VDC
  • Low battery trip: 40 VDC-42VDC
  • High voltage alarm: 64 VDC
  • Low battery voltage restart: 53.2 VDC
  • Idle consumption: 1.67 amps DC
  • Power saver mode idle consumption: <.83 amps DC
  • Charger Output voltage: Depends on battery type
  • Charger rate: 60A
  • Unit weight: 80 lbs.
  • Unit size: L x W x H: 23.5x 8.74 x 7.10 inches
  • Transfer Switch: 75 amp @ 120 Vac and 40 AMP @ 240
Product Specifications (Right Column)

Package Contents:

  • Aims Inverter
  • Owner's manual
WARRANTY
1 Year Manufacturer Warranty
Manuals & Documentation

Customer Reviews

Based on 2 reviews
50%
(1)
0%
(0)
0%
(0)
0%
(0)
50%
(1)
A
A.
Disappointing products and service

I bought this for an RV that has both 120v & 240v components onboard. I should have researched more thoroughly before ordering as this unit cannot accept 120v shore / line power, which is what is available to us at most locations such as RV parks and family and friends homes. It never occurred to me that there was any chance the unit would not accept 120v shore power as this unit retails for over $1900, whereas my significantly cheaper $559 Powerjack 8000 watt 120/240 inverter charger does accept 120v shore power. I assumed that if the less expensive brand had this basic feature that surely the expensive brand would as well.

I spent over $14,000 on Aims equipment. This inverter has been a disappointment. And after having Aims LCD remote fail within a week and then worse yet having Aims lithium battery model LFP48V150A / LFP24V300A fail to operate properly out of the box (which retails at $5299), and the subsequent unsatisfactory support experience I had with Aims, I give up on this brand. I was warned by a professional builder to not go with Aims due to high product failure and poor service. I sure wish I had listened. That builder made the switch to Victron. I'm now considering either Victron, Renogy, or Magnum myself.

m
m.m.
Wow, just wow

Have not got the system up as of yet but let me tell you this thing is enormous, very heavy and this was the only place I could get it at lowest price, free shipping and no taxes. That's a savings of $ 140. Just in taxes.
