Aims Power PWRINV8KW12V 8000 Watt Power Inverter New

Manufacturer: Aims Power

SKU: PWRINV8KW12V

Aims Power PWRINV8KW12V 8000 Watt Power Inverter New
Aims Power PWRINV8KW12V 8000 Watt Power Inverter New
Aims Power PWRINV8KW12V 8000 Watt Power Inverter New



Aims Power PWRINV8KW12V 8000 Watt Power Inverter New
Aims Power PWRINV8KW12V 8000 Watt Power Inverter New
Aims Power PWRINV8KW12V 8000 Watt Power Inverter New

QTY

Add to compare
Add to wishlist

$ 804.00

+
shipping box
FREE Shipping
×

This item ships for free. Freight shipments include liftgate at no additional charge.

Sign up for restock notifications!

Notify Me
headset icon

Exceptional Customer Service


headset icon

Authorized Dealer

Product Overview

Power inverters have become a staple in businesses and homes around the world due to intermittent brown and black-outs. The 8000 watt 12 volt AIMS Power inverter Inverter technology at its finest - AIMS Power’s brand new 8000 watt 12 volt modified sine inverter is smaller, lighter, and more efficient. AIMS Power’s old model of this inverter is still trusted and will be trusted long into the future among business owners, especially mobile businesses, all around the world. AIMS Power developed a new version of the 8000 watt inverter due to the development of new technology and the inverter’s high demand among AIMS Power customers.
vendor logo
divider
authorized dealer
checkmark

Brand new in box

checkmark

Manufacturer direct shipping from NV

checkmark

Factory Warranty Included

checkmark

Authorized Aims Dealer

Aims Power PWRINV8KW12V 8000 Watt Power Inverter New

Aims Power PWRINV8KW12V 8000 Watt Power Inverter New

Features

  • 8000W max continuous power
  • Modified sine wave
  • Volt meter on front panel to monitor your battery voltage
  • Amp meter on front panel to monitor your current use (rate at which battery is drained)
  • Over Temperature LED indicator
  • Over Load LED indicator
  • AC direct connect terminal block
  • Over Temperature protection
  • Over Load protection
  • Single cooling fan thermally controlled
  • Internally fuse protected
  • AC output short circuit protection
  • Auto reset on most fault conditions
  • Aluminum case for optimal cooling
  • Pre-wired for remote on/off switch
  • Pre-slotted mounting plate
  • This inverter requires 2 sets of 4 AWT cable if you are going to run at 8000 watts
  • 1 Year Warranty Parts and Labor

Specifications

Continuous output power 8000 Watts
Surge power capability (peak power) 16000 Watts
DC input / operating voltage 10 to 15 Volts
Output voltage 120 Volts ac +/- 10%
Output wave form Modified sine wave with phase correction
Output frequency 60 Hz +/- 1 Hz
Battery low voltage alarm 10.5 +/- 0.5 Volts
Battery low voltage shutdown 10.0 +/- 0.5 Volts
No load current < 1.3 DC amps
Full load efficiency 90%
1/3 load efficiency 95%
No load minimum operating temperature 30ºF
Full load maximum operating temperature 140ºF
AC Output Socket Type Quadruple Type 2 -3 prong
High input voltage protection 15V-17V
Low input voltage shutdown 10V Internal fuse protection
Product size (L x W x H) 19.02”X 7.76”X 6.02”
Weight 19.8 lbs
UL maximum recommended per outlet 1500W

Package Contents

Aims Inverter

Owner's manual

Warranty

vendor logo
divider
authorized dealer

1 Year Manufacturer Warranty

Manuals & Documentation

Customer Reviews (1)

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
K
Karen Davis
Review

Came in quick, technology has advanced, much smaller and quieter than our last and handles more power.
