2D Keystone
2D keystone correction provides installation flexibility by correcting the trapezoid effect via horizontal and vertical adjustments up to ±30 degrees. With it, the projector can be placed off center, allowing the presenter to stand in front of the screen without blocking the image. The projector can also be placed anywhere on a u-shaped tabletop without moving the table or putting a stand in the center. |
Corner Fit
Corner fit is a flexible and convenient way to align the picture perfectly by adjusting each corner of an image independently. |
MHL Connectivity
With MHL you can present your business proposals and share your ideas instantly using your Android smart device. Turn small screen into big screen by mirroring documents, photos, videos and any other content in your smart device onto the projection screen. Once connected, the projector supplies power to the smart device, keeping it charged so you don’t run out of battery power while presenting.
SmartEco™ Technology for energy conservation
BenQ’s SmartEco™ Technology helps lower total cost of ownership while optimizing projector performance through dynamic power savings. Providing uncompromised brightness, exquisite picture quality and incredibly long lamp life. |
Eco Blank Mode
The Eco Blank feature allows users to blank or mute the projected image on the screen, affording privacy to search for files or documents while the desktop is not projected to the entire audience. When activated, Eco Blank automatically dims lamp power, therefore lowering total power consumption by up to 70%.
Full Power On |
Eco Blank Mode On |
SmartEco™ Lamp Saving Technology
Incorporating BenQ’s renowned SmartEco lamp saving Technology, the MH741 provides great energy savings while continuing to deliver amazing picture quality through this innovative technology. SmartEco mode is designed to use only the exact amount of lamp power a projector needs to deliver the best contrast and brightness performance. This feature enables the MH741 to deliver uncompromised projection quality with the added benefit of reduced the total cost of ownership by greatly extending lamp life and lowering power consumption.
Normal Mode |
SmartEco Mode |
No Source Detected Mode
There will be times when a projector is turned on without a display source, such as a notebook or classroom PC connected. To avoid having a projector running at full lamp power, BenQ created the No Source Detected feature, which lowers the projector’s lamp brightness to 30 % after the projector has remained unconnected to a display source for more than three minutes.
Source Detected |
No Source Detected |
0.5W in Standby Mode
When inactive, the MH741 keeps power consumption to a minimum, <0.5W standby power, achieving a level of energy savings that was once considered unattainable, reducing the total cost of ownership while helping save resources.
Built-in 10W Speaker Power
A powerful built-in 10W speaker the MH741 delivers crisp, clear audio to fill even the largest rooms. Allowing your message to be clearly heard. |
Specifications:
Model | MH741 |
Enviromental Notice |
Lamp in this product contains mercury. To dispose of the product or used lamps, consult your local environment authorities for regulations. |
Projection System | DLP |
Native Resolution | 1080p (1920 x 1080) |
Brightness* (ANSI Lumens) | 4000 ANSI Lumens |
Contrast Ratio | 10000:1 |
Display Color | 1.07 Billion Colors |
Lens | F= 2.59-2.87, f=16.88-21.88mm |
Aspect Ratio | Native 16:9 (5 aspect ratio selectable) |
Throw Ratio | 1.15-1.49 (Wide 95” ±3% @ 2.42m) |
Image Size (Diagonal) | 60"~196" |
Zoom Ratio | 1.3x |
Lamp Type | 260W |
Lamp Mode (Normal/ Economic/ SmartEco/ LampSave/ LumenCare)* | 2000/3500/4000 hours |
Keystone Adjustment |
2D, Vertical & Horizontal ± 30 degrees; Auto vertical keystone ± 30 degrees |
Projection Offset | Vertical: 130% ±5% |
Resolution Support | VGA(640 x 480) to WUXGA_RB(1920 x 1200)*RB = Reduced blanking |
Horizontal Frequency | 15 - 102KHz |
Vertical Scan Rate | 23 - 120Hz |
Interface |
Computer in (D-sub 15pin) x1( integrate with component) |
Dimensions (W x H x D mm) | 12.36" x 4.5" x 8.5" (314.2x116x216.3mm) |
HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
Video Compatibility | NTSC, PAL, SECAM |
3D Support and Compatibility |
Frame Sequential: Up to 60Hz 720p |
Weight | 7.25 lb (3.3 kg) |
Audible Noise (Normal/ Economic Mode) | 36/31 dBA |
Power Supply | AC100 to 240V, 3.5A, 50 to 60 Hz |
Power Consumption | 330 W(Normal), 270 W(Eco), Standby <0.5W |
On-Screen Display Languages | Arabic /Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai /Traditional Chinese (28 Languages) |
Accessories (Standard) |
Power Cord (by region) Remote Control w Battery VGA cable User Manual CD QSG Lens Cover Warranty Card (by region) |
Accessories (Optional) |
Spare Lamp Kit P/N: 5J.JEA05.001 Video Streaming Dongle - Qcast P/N: 5J.JCK28.A01 Ceiling mount kit P/N: 5J.JAM10.001 Carry bag P/N: 5J.JCM09.001 3D Glasses P/N: 5J.J9H25.001 |
