Product Overview

Champion’s 8.5-kW Home Standby Generator system provides 24/7 power for your home and peace of mind for you. This fully automatic unit is the quietest-in-class and never needs refueling.

vendor logo
divider
authorized dealer
checkmark

10 year manufacturer's limited warranty

checkmark

Ships directly from Champion out of CA

checkmark

Fast processing with free shipping

checkmark

Authorized Champion dealer

Champion 100177 8.5kW Home Standby Generator Nema 3R Transfer Switch New

Champion 100177 8.5kW Home Standby Generator Nema 3R Transfer Switch New

Features

  • Totally Automatic- The ATS50 Emergency Essentials Automatic Transfer Switch has 12 available circuits available and provides seamless power to your home during an outage
  • Quietest-in-Class- Thanks to advanced sound dampening and a specially designed low-tone muffler, this generator operates at a residential-friendly 59.5 dBA noise level
  • Reliable- 24-volt starting system operates in sub-zero or extreme heat (between -22° F and 104° F) with no warming kit necessary, plus the generator performs weekly self-diagnostic tests
  • Powerful- The 8.5-kilowatt generator provides 8500 watts of continuous power on propane and 7500 watts on natural gas, with no refueling, no manual operation and no extension cords needed
  • Champion Support Includes 10-year limited warranty with FREE lifetime technical support from dedicated experts
  • 50-Amp Outdoor-Rated 8-Space Load-Center ATS

Specifications

Propane Rated Watts8500W
Natural Gas Rated Watts7500W
Propane Rated Amps at 120V70.8A
Propane Rated Amps at 240V35.4A
Natural Gas Rated Amps at 120V62.5A
Natural Gas Rated Amps at 240V31.3A
Rated Volts120/240
Rated Frequency60Hz
PhaseSingle
Propane Fuel Consumption at 1/2 Load1  gal/h
Propane Fuel Consumption at Full load1.5 gal/h
Natural Gas Fuel Consumption at 1/2 Load97.5 ft3/h
Natural Gas Fuel Consumption at Full Load139.8 ft3/h
Main Line Circuit Breaker35.5A
Starting System Automatic24V
Operational Volume59.5 dBA
Cooling SystemAir Cooled
AC Ton Rating3T
Generator EnclosureSteel
Generator Mounting PadComposite
Engine BrandChampion
Engine Size439cc
Engine Type4-stroke
Engine Speed3600
Fuel TypePropane (LPG), Natural Gas (NG)
Engine Oil TypeMobil 1 5W-30 Full Synthetic
Engine Oil Capacity1.2 qt.
Engine Oil IncludedNo
Low Oil Shut-OffYes
UL ListingcULus
EPA CertifiedYes
Switch Amps50A
Switch Volts120/240
Switch TypeSelect Circuit
Switch Circuits12
Switch Poles2
Load ManagementNo
Service Entry RatedNo
Switch EnclosureNEMA 3R
Length49 in.
Width28 in.
Height28 in.
Weight365.1 lb.

Package Contents

8.5kw Standby Generator

NEMA 3R Transfer Switch

All weather composite mounting pad

Oil Drain Pan

Flexible Fuel Line

HSB Enclosure Keys

Battery Cables & Hardware

LPG Jets

Jet Change Tool

User's Manual

Warranty
