Cummins Onan QG 6500 6.5kW Generator 6.5HGJAE Commercial Mobile Propane Single Phase Air Cooled New
Manufacturer: Cummins
SKU: A063B634
Share
Email
QTY
$ 7,701.00
+
FREE Shipping
×
This item ships for free. Freight shipments include liftgate at no additional charge.
Sign up for restock notifications!
Exceptional Customer Service
Manufacturer Direct
Product Overview
The Cummins 6.5HGJAE is designed for tough commercial applications. This generator includes exceptionally low noise and vibration, easy installation, diagnostic capability and digital regulation which maintains voltage stability as loads change. Cummins backs this generator with a standard 2 year limited warranty.
+ Evaporative control model required for applications using a fuel tank separate from the propulsion engine.
2 year factory warranty
Brand new in box
Propane powered
Authorized Cummins dealer
Similar Products
COMPARE SIMILAR ITEMS
Customers Also Purchased
Features
- 4-cycle Air-cooled, single cylinder engine for reliable consistent power
- Easy maintenance with single-side service.
- Microprocessor control with diagnostics and lightweight, compact design.
- Completely enclosed with muffler, quick and easy to install.
- Meets National Park Service sound level requirements (60 dB(A) @ 50 ft) for use in national parks.
- 2-year limited warranty
Specifications
| Manufacturer | Cummins |
| SKU | 6.5HGJAE-2145, 6.5HGJAE-3554 |
| Model Number | QG 6500 |
| Alternate Model Number | A063B634, A063B637 |
| Generator Grade | Commercial |
| Generator Style | Commercial Mobile Generator |
| Engine/Motor Brand | Cummins |
| Fuel Type | LP (Propane) |
| Starting System | Electric |
| Horsepower | 20.0 HP |
| Engine/Motor Type | Air-Cooled, OHV, 90-degree V-twin |
| Displacement | 653 cc |
| Engine RPM | 2880 RPM |
| Generator RPM | 2880 RPM |
| Fuel Tank | Not included |
| LP Consumption 100% Ld | 1.2 |
| Fuel Induction System | Carburetor |
| Engine Governor | Mechanical |
| Operational Volume (dB @10ft) | 70.0 |
| Muffler/Exhaust | Enclosed Spark-Arrestor |
| Evaporative Emissions Control Equipped Model | No, generator is NON-EVAP and is not evaporative emissions compliant. Your generator application/installation requires its own evaporative emissions standards compliance measures. |
| Altitude Affected | Yes |
| Vibration Isolators | Coil Spring |
| Battery For Electric Start | Not Included |
| 2 Year (Limited) | Weight (Lbs.) |
| 299 | Ship Weight (Lbs.) |
| 339 | Operating Weight (Lbs.) |
| 299 | Dimension No Wheel Kit |
| 22.2"W x 33.6"L x 16.7"H | Agency Compliance |
| CARB (California), EPA, National Park Approved | Surge Start Watts |
| 6,500.0 | Continuous Rated Watts |
| 6,500.0 | Prime Rating Watts |
| 6,500 | Phase |
| Single-Phase | Voltage |
| 120, 240 | Rated Amps @ Min Volt (Commonly 120v) |
| 54.1 | Rated Amps @ Max Volt (Commonly 240v 1-Phase) |
| 27.0 | Frequency |
| 60 Hz | Power Factor |
| 1.0 | Poles |
| 2 | Alternator |
| Brush | Voltage Regulation |
| 1.7% | Voltage Regulation Type |
| Digital | Circuit Breakers |
| 30 Amp | Insulation |
Package Contents
Cummins Onan QG 6500 Propane Generator
User's manual
Warranty
This item comes with a 2 year factory warranty.
