Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New

Manufacturer: Goodyear

SKU: GUL001

Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New
Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New
Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New
Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New
Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New
Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New

QTY

(888) 999-1522

$ 299.99

+
shipping box
FREE Shipping
×

This item ships for free. Freight shipments include liftgate at no additional charge.


or

Pay Over Time

Select Bread as your payment at checkout

divider
in stock checkmark

In Stock

truck icon

Ships Same or Next Day

If ordered by 12PM EST

Extended Warranty

×

Factory Warranty

  • Warranty covers any defects in workmanship and materials for a period of one (1) year from the date of purchase.

Extended Warranties

  • Brand New

    Extends factory warranty to 2, 3, or 5 total years

  • Brand New

    Covers functionality issues for 2, 3, or 5 years

  • Brand New

    Local repair options always available

  • Brand New

    Free replacement if repair is not possible

  • Brand New

    No deductibles or hidden fees

  • Brand New

    Full parts and labor coverage

$0

(Included)

  • Warranty covers any defects in workmanship and materials for a period of one (1) year from the date of purchase.

$39.00

(Details)

  • Brand NewExtends factory warranty to 2 total years
  • Brand NewCovers functionality issues for 2 years
  • Brand NewLocal repair options always available
  • Brand NewFree replacement if repair is not possible
  • Brand NewNo deductibles or hidden fees

$59.00

(Details)

  • Brand NewExtends factory warranty to 3 total years
  • Brand NewCovers functionality issues for 3 years
  • Brand NewLocal repair options always available
  • Brand NewFree replacement if repair is not possible
  • Brand NewNo deductibles or hidden fees

$89.00

(Details)

  • Brand NewExtends factory warranty to 5 total years
  • Brand NewCovers functionality issues for 5 years
  • Brand NewLocal repair options always available
  • Brand NewFree replacement if repair is not possible
  • Brand NewNo deductibles or hidden fees

Warranty has been added in! Please click add to cart.

headset icon

Exceptional Customer Service

headset icon

Manufacturer Direct

Shopper Award
FactoryPure BBB Business Review
Goodyear 3.2 GPM 1/4

Goodyear 3.2 GPM 1/4" NPT Air Inlet 1/2" NPT Male Oil Outlet Air-Powered Oil Transfer Drum Pump New

Product Overview

Our Transfer Pumps are double action and self priming designed, delivering fast and precise flow rates. This smart design uses fewer parts for less pump wear and tear, making it easy to use and maintain. This pump is best suited for multiple fluid types of medium to high viscosity at a short to medium distance. Typical fluids handled include: motor oil, synthetic oil hydraulic, gear oil, automatic transmission fluid and suitable up to SAE240 grade oil.

vendor logo
divider
authorized dealer
checkmark

1 year factory warranty

checkmark

Brand new in box

checkmark

Ships directly from Goodyear out of CA

checkmark

Authorized Goodyear dealer

Features

  • PUMP SPECS - This Air Operated (Pneumatic) Double Action Oil Transfer Pump has a High Flow rate of a Max 3.7GPM / 14LPM; A Max Pressure Ratio of 5:1; A Max Air Inlet Pressure of 5-8BAR / 70-115PSI; A Max Fluid Pressure of 40BAR / 115PSI; An Air Motor Effective Diameter of 63mm 2.5"inch; An Air Consumption (per minute) at 8BAR / 125L at 115PSI / 4.5CFM; An Air Inlet Connection of 1/4" inch and Oil Outlet Connection of 1/2" inch Male; A Long Pump Life of 420k Liters / 110k+ Gallons
  • SAFE and PROPER USE - All our pumps come with a 2" inch Adjustable Bung adapter, for easy installation for barrel-mounted applications; This pump can be a barrel, cart or wall mounted; A Wall Mount Kit or Extension Tube Kit is Sold SEPARATELY; Follow manual for setup and always use the proper additional equipment as listed in the manual when installing the pump and always wear protective glasses/goggles or gear when operating equipment

Specifications

Drum application Wall mounted
Pressure ratio 5 to 1
Air inlet pressure 5-8bar / 70-115psi
Max. fluid pressure 40bar / 580psi
Air motor effective diameter 63mm / 2.5"
Air consumption (per minute) @ 8bar / 125L / @ 115psi / 4.5CFM
Max. free flow rate (per minute) 14L / 3.7gallon
Suction tube diameter 42mm / 1-5/8"
Suction tube length 270mm / 10-5/8"
Air inlet connection 1/4" quick plug / 1/4" NPT Female
Oil outlet connection 1/2" M
Temperature oil delivered -10~50°C
Noise level(dB) 82

Package Contents

Air Powered Oil Transfer Drum Pump

Instruction Manual

Warranty
