Hobart 500575 Airforce 27i 120/240V Plasma Cutter with XT30R Torch and MVP Power Cord System Manufacturer RFB

Manufacturer: Hobart

SKU: 500575R

Hobart 500575 Airforce 27i 120/240V Plasma Cutter with XT30R Torch and MVP Power Cord System Manufacturer RFB

Hobart 500575 Airforce 27i 120/240V Plasma Cutter with XT30R Torch and MVP Power Cord System Manufacturer RFB

QTY

$ 1,199.00

+
shipping box
FREE Shipping
×

This item ships for free. Freight shipments include liftgate at no additional charge.

Sign up for restock notifications!

Notify Me
headset icon

Exceptional Customer Service

headset icon

Manufacturer Direct

Shopper Award
FactoryPure BBB Business Review
Hobart 500575 Airforce 27i 120/240V Plasma Cutter with XT30R Torch and MVP Power Cord System Manufacturer RFB

Hobart 500575 Airforce 27i 120/240V Plasma Cutter with XT30R Torch and MVP Power Cord System Manufacturer RFB

Product Overview

The Hobart AirForce® 27i Plasma Cutter With Multi-Voltage Plug is an economical plasma cutter system for all conductive metals. Inverter-based design features a multi-voltage plug (MVP) that allows a user to connect to common 120V or 240V power receptacles.   The XT series torch and long life XT tips and electrodes provide added performance to an already exceptional plasma cutter.



Plasma cutters cut faster and more precisely with a thinner kerf and less slag than cutting with oxy fuel. A smaller heat-affected zone also causes less warping. And you'll never have gas pressure settings, flame tuning, metal preheating or gas cylinders or refills to worry about.



Refurbished units are clean condition and most look brand new, but some may have some minor dings. Most are unused returns that have never been fired up except during testing. If there has been prior use, it is very minimal. Our welders are manufacturer refurbished by Hobart. All units are fully tested for performance and guaranteed to work like new. They come with a one year manufacturer's warranty.

vendor logo
divider
authorized dealer
checkmark

1 year limited factory warranty

checkmark

Includes all original accessories

checkmark

Manufacturer refurbished

checkmark

Ships directly from Hobart out of WI

checkmark

Authorized Hobart dealer

Features

  • Dual-Voltage capability with MVP (Multi-Voltage Plug) allows you to connect to common 120 or 240V power receptacles without the use of any tools, simply choose the plug that fits the receptacle
  • Clean cuts 3/8in. mild steel; severs steel up to 5/8in. thick
  • XT30R torch is designed for increased comfort with an ergonomic trigger safety, more efficient cooling and economical replacement cutting tips
  • Wind Tunnel Technology™ prevents abrasive dust and particles from damaging internal components
  • Fan-On-Demand™ cooling system operates only when needed, reducing power consumption and contaminants drawn into the machine
  • Power Factor Correction (PFC) circuitry draws up to 30% less amperage for the same cutting range when compared to the competition, expanding an operator's work area via extension cord, while minimizing nuisance circuit breaker trips caused by voltage drops
  • Internal gas/air filter and regulator controls the amount of usage and flow, or air or gas
  • Starts without high frequency protecting the unit by not interfering with or damaging controls or computers
  • Diagnostics LED lights for quick troubleshooting of pressure, power and cup situations
  • Postflow cooling circuit extends the life of consumables and torch by cooling them with postflow air after the trigger is released
  • Compatible with engine-driven welders, delivering complete cutting capability when powered by an engine-driven welder/generator with 240V receptacle of 4 kW or more
  • LVC™ line voltage compensation provides peak performance power under variable input voltage conditions (+/- 15%) for steady and cleaner-ending cuts

Specifications

Volts120/240
Compressor IncludedNo
Amps14–30
Cutting Thickness (in.)3/8 (mild steel, clean cut)
Sever Thickness (in.)5/8
Duty Cycle120V (15A) 20A at 88 VDC, 60% duty cycle; 120 V (20A) 27A at 92 VDC, 35% duty cycle
Clamp Cable Length (ft.)12
Power Cord (ft.)12
CartNo
Dimensions L x W x H (in.)13 1/2 x 6 x 9
Ship Weight35.0 lbs

Package Contents

12 ft. XT30R hand-held torch

12 ft. work cable with clamp

10 ft. power cord with 5-15P (120V, 15A) and 6-50P (240V, 50A) MVP™ Plugs

Easy-to-connect, built-in gas/air filter and regulator for extra protection

Extra consumables (2 tips, shield deflector, and electrode)

Cable management

Warranty

vendor logo
divider
authorized dealer

This item comes with a 1 year limited factory warranty.

Customer Reviews (1)

Customer Reviews

03/20/2022
TIM TOWNE
5*

I was skeptical about buying a "refurbished" unit but it was $500 cheaper than new. It was in like new condition with all of the assesories and manuals. Cuts thru steel like a hot knife thru butter.
I'm very satisfied with my purchase!
