Kubota GL11000TM Generator 11kW Diesel Liquid Cooled 120/240V CARB with Output Terminals New
Manufacturer: Kubota
SKU: GL11000-USA-TM
QTY
or
(888) 999-1522
$ 10,153.00
This item ships for free. Freight shipments include liftgate at no additional charge.
In Stock
Ships in (est) 1 business day
Manufacturer Direct Shipping
Exceptional Customer Service
Authorized Dealer
Kubota GL11000TM Generator 11kW Diesel Liquid Cooled 120/240V CARB with Output Terminals New
Product Overview
The Kubota GL11000-TM is a diesel generator built to deliver reliable power for demanding applications. Its direct-coupled generator and engine design helps provide dependable output with minimal power loss. The unit is designed for easier ownership with one-side maintenance access and extended oil change intervals up to 200 operating hours. Safety-focused shutoff protection and ATS connection capability make it well suited for stationary and heavy-duty use. This unit features output terminals and one standard 5-20R GFCI receptacle.
Brand new
3 year / 3000 hour warranty
Manufacturer direct shipping from TX
Authorized Kubota dealer
Plug Types
×1
20 Amp GFCI Standard Receptacle
(20A-GFCI)
Plug Types
×1
20 Amp GFCI Standard Receptacle
(20A-GFCI)
Features
- Generator and engine are direct-coupled to ensure a more reliable power supply with minimum power loss.
- Large-capacity fuel tank (28L/7.4 U.S. gal.) enables longer continuous operation on a single tank.
- One-side maintenance to reduce the operator’s work load.
- Larger-capacity oil pan employed to stretch the oil change intervals up to 200 operating hours.
- Protective covers on all moving parts (for the engine’s cooling fan and the generator).
- Automatically shuts the engine down in case the water temperature rises excessively or the oil pressure drops below a safe level.
- Double element air cleaners are standard equipment. Ideal for heavy-duty application in dusty environments.
- An access terminal to connect to the ATS (Automatic Transfer Switches) is standard equipment. Applicable for stationary use as well.
Specifications
| Model | GL11000-TM |
| Frequency | 60 Hz |
| Prime Output | 10 kVA |
| Standby Output | 11 kVA |
| Voltage | 120/240 V |
| Phase Wire | 1/3 |
| Power Factor | 1.0 |
| Single Phase 120 V | 83.4 A |
| Single Phase 240 V | 41.7 A |
| Engine Type | Vertical 4-cycle liquid cooled diesel engine |
| Engine Model | D722 |
| Engine Speed | 3600 rpm |
| Starting System | Electric 12 volt DC |
| Fuel | Diesel |
| Fuel Consumption 100% Load | 4.1 L/hr 1.1 gal/hr |
| Fuel Consumption 50% Load | 2.7 L/hr 0.71 gal/hr |
| Fuel Tank Capacity | 28.0 L / 7.39 gal |
| Continuous Operating Hours 100% Load | 7.0 hours |
| Continuous Operating Hours 50% Load | 10.4 hours |
| Battery | 12V x 36 Ah |
| Dimensions | 50.43 x 24.3 x 27.5 in |
| Net Weight | 701 lbs |
| Sound Level Full Load at 23' | 68.0 dBA |
Package Contents
Kubota GL11000-TM Generator
User Manual
Warranty
This item comes with a 3 year / 3,000 hour warranty.
