Makinex 23000W/24100W Generator 120V/480V Dual Phase Gas Vanguard Engine Electric Start New
Manufacturer: Makinex
SKU: GEN-23P-MS-480
QTY
or
(888) 999-1522
$ 16,600.00
This item ships for free. Freight shipments include liftgate at no additional charge.
In Stock
Ships in (est) 2-3 business days
Manufacturer Direct Shipping
Exceptional Customer Service
Authorized Dealer
Similar Products
Makinex 23000W/24100W Generator 120V/480V Dual Phase Gas Vanguard Engine Electric Start New
Product Overview
Less than one third the size and weight of comparable towable and SKID generators, the 23kW is the world's smallest 3-phase 480V generator in its class. The 23kW 480V is so small it fits in your equipment trailer or truck, and fits through standard doorways. This generator uses permanent-magnet brushless alternator technology and has totally independent circuits for 120V and 480V. Equipped with industry-standard 50A, 30A, and 20A outlets, the 23kW 480V can power multiple single-phase and 480V three-phase equipment at the same time with no requirement for voltage selection.
Brand new
1 year limited warranty
Manufacturer direct shipping from TX
Authorized Makinex dealer
Plug Types
×2
120v 20 Amp Standard Receptacle
(5-20R)
×1
250v 50 Amp Twist Lock
(CS8369)
×1
480v 30 Amp Twist Lock
(L16-30R)
×1
250v 30 Amp Twist Lock
(L6-30R)
Plug Types
×2
120v 20 Amp Standard Receptacle
(5-20R)
×1
250v 50 Amp Twist Lock
(CS8369)
×1
480v 30 Amp Twist Lock
(L16-30R)
×1
250v 30 Amp Twist Lock
(L6-30R)
Features
- Light and small enough to carry on your truck
- Independent single and 3-phase power generation
- Simultaneous single and three phase operation
- Highly portable with four large wheels
- Briggs & Stratton Vanguard V-Twin OHV engine
- Electric/Key Start
Specifications
| Voltage | 120V Single Phase; 480V Three Phase |
| Rated Output | 23000W |
| Max Output | 24.1kW |
| Max Amps Single Phase | 30A @ 120V |
| Max Amps Three Phase | 50A @ 480V |
| Sockets Provided | 50 Amp 480V 3-phase / 30 Amp 480V 3-phase / 120V GFCI |
| Engine Type | Twin Cylinder Air Cooled Petrol |
| Engine Model | Vanguard 61G277 |
| Starting System | Electric Key Start |
| Displacement | 993cc |
| Fuel Economy | 1.5 gal @ 50% load |
| Fuel Tank | 13.2 gal. |
| Noise Level | 50% Load - 80 dB |
| Product Dimensions | 43" x 25" x 40" |
| Weight | 573 lbs |
Package Contents
Makinex Dual Phase Generator 23kW 480V
User Manual
Warranty
This item comes with a 1 year limited warranty.
