| Manufacturer's Warranty |
2 Yr Consumer Limited |
| Power Supply |
208~230v, 60Hz, 1Ph
|
| Rated Cooling Capacity |
24,000 BTU
|
| Cooling SEER |
17,500 BTU
|
| Rated Heating Capacity |
23,800 BTU
|
| Heating HSPF |
9,500 BTU
|
| Refrigerant Type |
R410a
|
| Suitable Area |
800 sq.ft
|
| Indoor Unit Data |
|
| Model |
DC024GMFI18HT2 |
| Air Flow |
800 CFM |
| Sound Level |
63db |
| Net Dimensions (WxDxH) |
19.6" x 21.6" x 46.5" |
| Carton Dimensions (WxDxH) |
22.6" x 22.6" x 47.8" |
| Net / Gross Weight |
119lbs. / 132lbs. |
| Outdoor Unit Data |
|
| Model |
YD024GMFI18MR2 |
| Sound Level |
75db |
| Net Dimensions (WxDxH) |
29.2" x 29.2 x 24.9" |
| Carton Dimensions (WxDxH) |
30.2" x 30.2" x 26.3" |
| Net /Gross Weight |
143lbs./152lbs. |
|
