Renogy RNG-DCC1212-40-US 12V 20A DC to DC On-Board Battery Charger New
Manufacturer: Renogy
SKU: RNG-DCC1212-40-US
QTY
(888) 999-1522
$ 155.24
This item ships for free. Freight shipments include liftgate at no additional charge.
Exceptional Customer Service
Authorized Dealer
Renogy RNG-DCC1212-40-US 12V 20A DC to DC On-Board Battery Charger New
Product Overview
Compatible with a multitude of alternator types, the DC-DC battery charger offers correct charging for AGM, Flooded, Gel, and even Lithium deep cycle batteries Featuring a 3-stage battery charger and multiple electronic protections, users can feel confident that their batteries are being charged optimally and automatically.
Easily install the compact yet sturdy DC-DC battery charger on RV's, commercial vehicles, boats, yachts, and many more applications.
1 year factory warranty
Brand new in box
Ships directly from Renogy out of CA
Authorized Renogy dealer
Features
- Various Protections For Ultra Safety: The DC-DC battery charger isolates the input and output to prevent voltage transmission errors and interfere with house battery charging. It has multifunctional safety technology including over-voltage protection, over-temperature protection, and reverse polarity protection to make it safer for use.
- Smart 3-stage Charging: The DC-DC battery charger will charge your house batteries from the starter battery by 3-stage charging (Bulk, Boost, and Float), to make sure it optimally and automatically charge to 100%.
- Prolong Battery Lifespan: The charger needs to select the charging mode according to the battery voltage. By utilizing the DC-DC temperature sensor, this charger is able to protect your battery from high or low temperature by giving -3mV/°C/2V compensation so that the charger recognizes the voltage more accurately and assures stable and constant charging to the battery. Please note the temperature sensor is not included and it cannot use with Lithium batteries.
- Compatible Multiple Battery Types: Compatible with a multitude of alternator types, the DC-DC battery charger offers correct charging for AGM, Flooded, Gel, and Lithium batteries.
- Protect Your Starter Battery: This Renogy DC-DC battery charger is compatible with traditional and smart alternators. The D+ Ignition cable is capable of identifying whether the generator is started, to prevent over-discharge of the starting battery and protect the generator. 18-16AWG copper cable recommended. Please note the D+ Ignition Cable is not included.
- Protect Your House Battery: The LC wire can automatically adjust the charging current to prevent excessive charging current from damaging the house battery. 18-16AWG copper cable recommended. Please note the LC cable is not included.
Specifications
| Dimensions | 10.3 x 6.9 x 2.7 in / 261 x 175 x 68 mm |
| Weight | 4 lbs. / 1.9 kg |
| Certification | CE ROHS |
| System Voltage | 12VDC |
| Equalization Voltage | N/A |
| Rated Charge Current | 40A |
| Float Voltage | 13.2-13.8v |
| Output | 500W Boost |
| Voltage | 14.1-14.7v |
| Idle Power Consumption | <0.4A |
| Operating Temperature | -20°C to +50°C |
| Input Voltage Range | 8V-16V |
Package Contents
40A DC to DC Battery Charger
User Manual
Warranty
This item comes with a 1 year material and workmanship warranty.
