Kohler 14RCA-QS6 14KW Standby Generator with OnCue Plus New

Share
Product Overview
Our most popular generators for backup power provide award-winning reliability and performance. When you lose power during an outage or storm, a hard-working 14/20 kW KOHLER® generator keeps your appliances working, the heat or AC running and your security system on. Now also available in 3 phase.



5 year comprehensive warranty
Remote Monitoring
Brand new in box
Free shipping
Works with liquid propane or natural gas
Authorized Kohler dealer
Features
- Every KOHLER® generator is equipped with a heavy-duty, commercial-grade engine that stands up to extreme weather
- In just 10 seconds, your KOHLER generator automatically restores power to a 5-ton (60,000 BTU) air conditioner, major appliances and electronics. Based on generator and load size
- We've got you covered with 5-year, 2,000-hour protection, and a corrosion-proof enclosure that's built to last
- KOHLER generators have received several awards, including the Most Valuable Product (MVP) Award 2010 by Building Products magazine
- PowerBoost™ technology provides power to start large loads such as central air conditioners without dropping power to other appliances
- Extraordinary peak motor-starting capacity: 14RCA at 33kVA at 240V
- Model 14RCA approved for off-grid applications with 18-month/1000-hour off-grid warranty
- Powered by reliable KOHLER Command PRO® engine, designed and tested for tough commercial applications; with hydraulic valve lifters to eliminate need for lengthy break-in periods and expensive valve adjustments; operation speed is 3600 rpm (the standard for air-cooled generators)
- Compatible with OnCue® Plus and OnCue® Plus Wireless Generator Management Systems, and Programmable Interface Module (PIM)
- Also compatible with Load Control Module (LCM) or Load Shed kit with single-phase generators only
- RDC2 controller designed for today's sophisticated electronics manages both the generator set and Model RXT transfer switch functions
- Quiet, neighborhood-friendly operation with sound levels similar to a typical central air conditioner
- Stylish corrosion-proof enclosure impact tested to -30°F
- Runs on either natural gas or liquid propane (LPG) with simple switching between natural gas and LPG in the field
- Streamlined installation, simple terminal block for easy field connections. Kohler also offers concrete mounting pads to lower installation costs and time.
- Premium power quality delivers exceptional digital voltage and frequency regulation along with low levels of harmonic distortion to protect sophisticated electronics
Specifications
Model | 14RCA |
Rated kW LP | 14 kW |
Rated kW NG | 12 kW |
Amps LP | 58 amps |
Amps NG | 50 amps |
Peak Motor Starting kVA @240 V | 33 kVa |
Alternator Note | All information shown is for 1 Phase 60 Hz generator with the largest alternator option available. |
Displacement | 725 cm³ (44 cu. in.) |
Horsepower | NG 20.5 HP, LP 23.6 HP |
Enclosure Material | Aluminum |
Sound Output During Weekly Exercise | 63 dB(A) |
Sound Output During Full-speed Operation | 67 dB(A) |
Response Time | 10 seconds |
Warranty | Premium five-year limited warranty |
Country of Origin | US |
Certifications/Listings | EPA, cUL, CSA, UL 2200 |
Automatic Transfer Switch | Sold Separately |
Remote Monitoring | Included |
Off Grid / Utility Backup | Utility Backup, Off Grid |
Weight | 440 lbs. (200 kg) |
Alternator Type | 2-Pole, Rotating Field |
Fuel Consumption on NG at 50% load | 124 cfh |
Fuel Consumption on LP at 50% load | 60 cfh |
Controller | RDC2 Controller |
Cylinder Arrangement | V-2 |
Dimensions | 1193 mm x 666 mm x 817 mm (47 in. x 26.2 in. x 32.2 in.) |
Engine Manufacturer/Description | KOHLER |
Engine Model | CH740 |
Engine/Alternator RPM | 3600 |
Fuel Type | Natural Gas, LPG |
Frequency | 60 Hz |
Phase | Single Phase or Three Phase |
Voltage @ 60 Hz | 120/240|277/480 |
Digital Voltage Regulation | ±1.0% |
Built in Mounting Pad | Yes |
Package Contents
Kohler 14RCA-QS6 14KW Standby Generator with OnCue Plus
User's manual
Warranty



This item comes with a 5 year comprehensive warranty.
