Operating System |
Linux (embedded) |
Pentaplex |
Simultaneous View, Record, Playback, Backup & Remote Monitoring |
Number of Channels |
8/16/32 Channels |
Video IN |
8ch: 8 PoE, 16/32ch: 16 PoE |
Video OUT |
No |
VGA OUT |
Yes |
HDMI |
Yes |
Audio IN |
1 Line IN (RCA) for service only |
Audio OUT |
1 Line OUT (RCA) for service only |
USB Port |
1 at the back, 1 at the front |
Alarm IN |
4 Alarm IN |
Alarm OUT |
2 Alarm OUT |
Video Output Resolution |
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
PTZ control |
Lorex IP PTZ cameras only |
Display |
8ch: 1/4/8, 16ch: 1/4/8/9/16, 32ch: 1/4/8/9/16/25/36 |
Live Display Speed |
8ch: 240fps NTSC / 200fps PAL, 16ch: 480fps NTSC / 400fps PAL, 32ch: 960fps NTSC / 800fps PAL |
OSD |
ON/OFF |
System Navigation |
USB Mouse, IR Remote Control, Front Panel Buttons |
Motion Area Setting |
Fixed Grid (22×18) |
Sensitivity Levels |
100 |
Firmware Upgrade |
Automatic over the Internet & via USB device and network |
User Authority |
By user group |
Time Synchronization |
Automatic time sync by NTP server |
Video Compression |
H.264 / H.265 |
Audio Compression |
G.711 |
Resolution |
Up to 4K (3840×2160), 1080p (1920×1080) |
Record Rate |
8ch: 240fps@720p/1080p/3MP/4MP/8MP, 16ch: 480fps@720p/1080p/3MP/4MP/8MP, 32ch: 960fps@720p/1080p/3MP/4MP/8MP |
Recording Resolution Setting |
Per camera for different resolutions |
Recording Quality Control |
6 Levels |
Recording Schedule |
By hour, by day, by recording mode, by motion, by alarm, by channel |
